Atari800

Version 7.2.1 (2026/09/13) — build fixes only ======================================== This release just fixes some build errors so for 7.2.x new features read below: Version 7.2.0 (2026/09/12) — on-screen keyboard and better joystick handling ============================================================================ Core: ----- * More accurate emulation: cycle-precise POKEY timer IRQs and VSCROL DLI timing; fixes the "Rewind 2" demo (#274) * Altirra OS updated to 3.49, Altirra BASIC to 1.59 * F1-F12 special keys (open-menu, OPTION, SELECT, START, etc.) can now be rebound via the UI * On-screen keyboard improvements: enabled by default, rebindable F11 hotkey, SDL2 controller button mapping, console key support * Dropped the /etc/atari800.cfg system-wide fallback on Unix * Fixed "Save Configuration" doing nothing on builds without screenshots * Acid800 suite wired into "make check" so every change is tested SDL joystick handling: ---------------------- * Hat or axes picked automatically from what the device reports; the -joy0hat..-joy3hat options were removed * Port settings renamed from JOY_%d_* to JOY_PORT_%d_* (old keys still accepted) * Ports remember their joysticks (and auto-detected defaults) across runs, even while disconnected * Small sticks default to fire trigger and wide diagonals * F1 menu and on-screen keyboard work with any host joystick, no port binding needed * Fixed SDL1 build Falcon/FireBee: --------------- * Precise POKEY IRQs, fixed sound latency, uSound v2 API * Stack/flags in LDFLAGS, mintelf target support re-introduced Android (Colleen): ------------------ * Hid the navigation buttons, made the console keys overlay less dim * Four drive icons shown in the menu only on very wide screens Build/CI: --------- * Falcon/FireBee and 32-bit builds added to CI * -Werror enabled, build warnings fixed * macOS universal (arm64 + x86_64) DMG fixed

Version 7.2.0 (2026/09/12) — on-screen keyboard and better joystick handling ============================================================================ Core: ----- * More accurate emulation: cycle-precise POKEY timer IRQs and VSCROL DLI timing; fixes the "Rewind 2" demo (#274) * Altirra OS updated to 3.49, Altirra BASIC to 1.59 * F1-F12 special keys (open-menu, OPTION, SELECT, START, etc.) can now be rebound via the UI * On-screen keyboard improvements: enabled by default, rebindable F11 hotkey, SDL2 controller button mapping, console key support * Dropped the /etc/atari800.cfg system-wide fallback on Unix * Fixed "Save Configuration" doing nothing on builds without screenshots * Acid800 suite wired into "make check" so every change is tested SDL joystick handling: ---------------------- * Hat or axes picked automatically from what the device reports; the -joy0hat..-joy3hat options were removed * Port settings renamed from JOY_%d_* to JOY_PORT_%d_* (old keys still accepted) * Ports remember their joysticks (and auto-detected defaults) across runs, even while disconnected * Small sticks default to fire trigger and wide diagonals * F1 menu and on-screen keyboard work with any host joystick, no port binding needed * Fixed SDL1 build Falcon/FireBee: --------------- * Precise POKEY IRQs, fixed sound latency, uSound v2 API * Stack/flags in LDFLAGS, mintelf target support re-introduced Android (Colleen): ------------------ * Hid the navigation buttons, made the console keys overlay less dim * Four drive icons shown in the menu only on very wide screens Build/CI: --------- * Falcon/FireBee and 32-bit builds added to CI * -Werror enabled, build warnings fixed * macOS universal (arm64 + x86_64) DMG fixed

Version 7.1.2 (2026/07/26) — keyboard joystick config fix ======================================================================= Core: ------ * Fixed keyboard joystick configuration dialog stuck in infinite loop

Version 7.1.1 (2026/07/26) — SDL2 joystick fixes ======================================= Core: ----- * Fixed keyboard joystick keys not working in SDL2 (only numpad keys worked) * Fixed joystick port mode "none" not persisting across restarts

Version 7.1.0 (2026/07/25) — cycle-precise POKEY interrupts ================================================== Core ---- * Implemented cycle-precise POKEY interrupts; Project-M now works correctly Android ----------- * Vertical, always-on console key overlay in landscape mode * Menu bar icons padded away from rounded screen edges * Disk drive mounting buttons (D1-D4) with mount status indicator * Fixed gzip disk image mounting (.atr.gz, .xfd.gz) CI -- * AppImage build improvements and fine-tuning * Fixed bashism, HTTPS certs, automatic release

Version 7.0.0 (2026/06/27) — the first Atari800 with built-in Internet downloads ================================================================================ New features: ------------- * Auto-download missing OS/BASIC ROMs from the Internet * Mount zipped disk images directly from the Internet * Portable mode — config file and data storage next to the executable Platform specific: ------------------ * Windows: 32/64-bit builds, installer executable, portable zip archive * Windows: app icon, MP3 recording support * Windows: win32-no-network build for XP compatibility * macOS: ready-to-run .dmg archive * Linux: AppImage builds (x86_64 + i386) * Android: auto-download ROMs, upgrade dialog Changes to config file search order: ----------------------------------- 1. --config argument — exact path given on command line 2. Portable exe dir — exe_dir/.atari800.cfg if exe dir is writable 3. $HOME default — ~/.atari800.cfg (if neither of the above applies) plus $HOME now respects MS Windows specifics (USERPROFILE etc.) If the resolved path (1, 2, or 3) doesn't exist: 4. HOME fallback — try ~/.atari800.cfg (only in portable mode) 5. System-wide — /etc/atari800.cfg (only if steps 1-4 all failed) 6. Fresh defaults — create new config at the path from step 1/2/3

Version 6.1.0 (2026/06/20) ========================== New features: * Alt+J opens Joysticks/Controller Configuration directly * **Save Configuration** moved to root F1 menu * Screenshot entries consolidated (Shift+F10 hint in label) Platform specific: * SDL: Alt+J hotkey added back

Version 6.0.0 (2026/06/19) ========================== New features: ------------- * SDL2 support — SDL2 is now the primary SDL target. Selected automatically when both SDL1 and SDL2 are available. Includes: - OpenGL shader support and improved rendering - SDL2 controller button configuration (map buttons to actions, D-pad UI) - Correct keyboard handling (CAPS-Lock, control letters, HELP with modifiers) * NetSIO / FujiNet support — network SIO over UDP, enabling connectivity with FujiNet devices. Supports high-speed divisors, PROCEED signal, port sharing (SO_REUSEADDR), and Windows (Winsock2). Configurable port via -netsio_port. * Paddle controller support (SDL2-only): - New JOY_MODE_PADDLE mode on any Atari port - Per-port configurable pot axes and fire buttons - Config keys: JOY_PORT_{0-3}_PADDLE_AXES, JOY_PORT_{0-3}_PADDLE_BUTTONS * Joystick configuration reorganised by Atari port (SDL2): - Each of the four Atari ports can be independently assigned an input source (None, Keyboard 1/2, host joystick, paddle, parallel port) - New config keys: JOY_PORT_{0-3}_{MODE,PARAM,NAME} - Host joysticks opened into a flat pool, assigned by name for persistence - Automatic smart defaults: if host joysticks are detected they are assigned to ports; otherwise port 0 defaults to keyboard * Support for J(atar)Carts & DCart cartridge types * Alternative key mapping for Atari 5200 Bounty Bob Strikes Back! * Turbo speed selection and quick save/load state * libatari800 API extensions: mount_disk(), unmount_disk(), disable_drive(), disk activity callbacks, SIO patch control * Monitor command enhancements: summaries and error codes added Changes: -------- * Sound system refactored: - VOL_ONLY_SOUND code removed (was unused and poor quality) - SYNCHRONIZED_SOUND and SOUND_THIN_API now forced on - SERIO_SOUND code removed * CPU emulation refactored for readability * Delayed NMI handling implemented per Altirra Hardware Reference Manual * SDL2: Removed -joy-distinct option (no longer needed with per-port assignment) * SDL2: Removed -joyswap / Alt+J swap joysticks shortcut * SDL: window stays open while using the monitor * SDL: joystick subsystem initialized only when needed * Falcon: -interlace parameter removed (use -refresh instead) * Falcon/FireBee: switched to m68k-atari-mintelf-gcc, usound routines * CAS/XFD detection order corrected * Host device letter input validation Bug fixes: --------- * Fix ATX handling on command line (bug since 2009, fixes #218) * Fix XF551 Get Status command (SuperDOS 5.1 timeout, fixes #190) * Fix Corina and other size-based BIN file loading (fixes #258) * Fix harmful typo in gtia.c (fixes #163) * Fix zero-length Fuji chunk read in img_tape.c * Fix Falcon/FireBee build * Fix compilation with --without-opengl and --with-sound=no * Fix make clean * Various compiler warning fixes Platform specific: ------------------ * Android: Complete overhaul — renamed to cz.pstehlik.colleen, SAF-based storage (no more FileSelector), Material Design icons, high-DPI console key scaling, auto-rotation, notch/cutout support, state save/load reworked, CMake/Gradle build system, BT and USB joysticks supported (up to four). * win32: DirectX/DirectDraw/GDI backend removed (use SDL on Windows). * Windows: NetSIO support via Winsock2 (netsiowin.c). * Falcon/FireBee: keyboard fixes, sound improvements, compiler update. * Dreamcast: redundant sound flag removed. * CI: Windows, macOS 14 arm64, and Ubuntu 20.04 build workflows added.

Version 5.2.0 (2023/12/29) ========================== New features: ------------- * possibility of renaming the host device "letter" from previously hardcoded H: to any letter but C: (cassette), E:, K: and S: So if you have e.g. a program with hardcoded "D:" (as for diskette) you can now use it on a host device as well by renaming the host device to D: either via the Emulation configuration -> Host device settings menu or using command line option `-Hdevicename ` * little thing but useful (for me at least): tooltip in the settings menu that reminds users there are virtual host devices with automatic ATASCIIASCII conversion (mainly end-of-line character). Extremely useful for all text files including ATARI BASIC source code that can be stored using LIST "H6:PROGRAM.LST" and read back using ENTER "H6:PROGRAM.LST" (H6 = H1 with ASCII conversion, etc.). **Full Changelog**: https://github.com/atari800/atari800/compare/ATARI800_5_1_0...ATARI800_5_2_0

Version 5.1.0 (2023/12/28) - released at SILK ========================== Thanks to all the contributors (see git log for each commit author) New features: ------------- * New command line options: -playbacknoexit => don't exit the emulator after playback finishes -joy-distinct => allows larger number of joysticks by not combining multiple physical devices into a single emulated joystick. For example this allows using keyboard to emulate one or two joysticks, and to use these in conjunction with physical SDL joysticks / controllers in order to play with more people than there are SDL joysticks. The same logic gets applied to LPT joysticks, these come after joysticks from keyboard emulation. Furthermore, the logic also gets applied to put SDL joysticks after LPT joystics even when the command line flag isn't set. Since LPT joysticks take precedence over SDL joysticks on the same emulated device, this takes a device that was completely ignored before and makes it useful now. The assignments are fixed at program start-up, after config file and command line flags have been taken into account. If the UI is used to enable or disable a keyboard-emulated joystick, this can cause an emulated joystick to be controlled by multiple physical devices, or by none. * Swap also SDL joysticks on AltL+J This swaps all physical devices connected to the first two emulated joysticks: the keyboard keys, the SDL devices, and the LPT devices. After the swap the real joystick / hat setting in the UI will appear swapped as well, but the keyboard setting won't (fixes #156). * Show all input events on a single line during recording This way the recording file alternates between two forms of lines: input lines which contain all keyboard and joystick events in one line, and output lines with the screen content digest. By filtering out the former, the latter can be aggregated nicely, e.g. using a command like this: `zcat ${file:?} | grep -vE '^[0-9A-F]{8} *$' | uniq -c` Consecutive frames of equal input state will be represented as a single row, with a repeat count giving an idea for how long the state was maintained. * RAM cartridges implementation (#184) - Many RAMCART and one SiDiCar cartridges - Support for writeable cartridges - CART monitor command - Make blank cartridge UI option - Reserved CART file ids for additional cartridge types currently unemulated by Atari800, added also the description of the types * added XEX reading in monitor (useful for patches) * Added H: device rename; save it in setup file (#204) Changes: -------- * Altirra OS updated to v3.41 * Altirra BASIC updated to v1.58 * Fix buffer over-read in generate_partial_pmpl_colls (#165) * Atari ST/TT/Falcon optimizations * Fixed keystrokes for inserting/deleting of line/character (#179) * SIO now resets BRKKEY (fixes Arsantica 3 demo) * Fix for issue #199 (BBSB warp doesn't work) * Fixes CTRL and CAPS keys when using SDL12-compat library. * DOC/README.RPI explains clearly support for various RaspberryPis ## New Contributors * @pfusik made their first contribution in https://github.com/atari800/atari800/pull/165 * @marcin-jozwikowski made their first contribution in https://github.com/atari800/atari800/pull/167 * @mirao made their first contribution in https://github.com/atari800/atari800/pull/179 * @jindroush made their first contribution in https://github.com/atari800/atari800/pull/185 * @mono6502 made their first contribution in https://github.com/atari800/atari800/pull/184 * @gagern made their first contribution in https://github.com/atari800/atari800/pull/197 * @jhusak made their first contribution in https://github.com/atari800/atari800/pull/201 * @Shamus397 made their first contribution in https://github.com/atari800/atari800/pull/203 **Full Changelog**: https://github.com/atari800/atari800/compare/ATARI800_5_0_0...ATARI800_5_1_0

Version 5.0.0 (2022/05/28) - released at Atariada.cz (yay!) ========================== Big thanks to all contributors (see git log for each commit author) New features: ------------- * AVI video recording (Alt+V hotkey) by Rob McMullen -vcodec command line arg can select video codec -aname and -vname CL args set patterns for sound and video recording -horiz-area & -vert-area command line args for controlling the image area -showstats (and -no-showstats) CL args and related config file param -compression-level for configuring PNG and ZMBV compression * MP3 audio and other audio codecs for audio recording (Alt+W hotkey) -acodec can select audio codec * New cartridge types supported: - 71: Super Cart 64 KB 5200 cartridge (32K banks) - 72: Super Cart 128 KB 5200 cartridge (32K banks) - 73: Super Cart 256 KB 5200 cartridge (32K banks) - 74: Super Cart 512 KB 5200 cartridge (32K banks) - 75: Atarimax 1 MB Flash cartridge (new) See DOC/cart.txt for details. * support for remapping of all function keys (START, SELECT, OPTION etc) * support for comments in config file * tool for creating cart files from ROM files * support for 64-512K Atari 5200 bank-switchable carts with Bryan's design * support for the alternate variant of MaxFlash 1 MB. * support for single RaspberryPi OS package with HW specific binaries Changes: -------- * video triple buffering changed to double buffering * fixed #74 by using proper getcwd() * gamma values in NTSC filter presets updated * MacOS build enables R: by default * fixed saving of config file * using zlib-provided crc32 if HAVE_LIBZ is defined (#72) * Altirra OS updated to v3.28 * renamed "Switchable 5200" cartridges to "Super Cart" * fixed segfault when a 5200 Super Cart cartridge is removed * avoided unnecessary memory copying of 5200 Super Carts * fixed #88 issue in opening a cartridge * BUILD instructions and new README for Android * fixed segfault when exiting monitor * fixed BBSB's lift not working * avoided unnecessary memory copying in Bounty Bob cartridges * allow configuring --with-audio=win in non-DirectX targets * allow configuring --with-audio=sdl and --with-video sdl * atari_x11.c: don't auto-repeat the 'screenshot' key * build compatible with dash ## New Contributors * @TheRobotFactory made their first contribution in https://github.com/atari800/atari800/pull/83 * @dbroda made their first contribution in https://github.com/atari800/atari800/pull/103 * @asiekierka made their first contribution in https://github.com/atari800/atari800/pull/72 * @mikekov made their first contribution in https://github.com/atari800/atari800/pull/123 * @kr0tki made their first contribution in https://github.com/atari800/atari800/pull/122 * @mgorny made their first contribution in https://github.com/atari800/atari800/pull/140 **Full Changelog**: https://github.com/atari800/atari800/compare/ATARI800_4_2_0...ATARI800_5_0_0

Version 4.2.0 (2019/12/28) - released at SILK ========================== New Features: ------------- * raw Pokey registers recording by Ivo van Poorten * new platform supported: FireBee * optional hiding of hidden files/folders in the UI file selector * libatari800 (Atari800 as a library) by Rob McMullen * R: device (many years old feature) enabled by default Fixes: ------ * proper check if SDL joysticks are found (fixes #58) * Portrait mode for Android (related to #41) * RMW for Pokey * Improved BASIC LST file loading (#55) * ROM OS path changes handled better (#15) * improved "Find ROM images" - now Atari800 reboots if necessary (#15) * fixed an old bug which caused freezing in the UI on Falcon New command line options: ------------------------- * -pokeyrec and its children * -atari_files (#29) * -saved_files (#29) * -kbdjoy0 -kbdjoy1 -nokbdjoy0 -nokbdjoy1 (#29) Plus many Atari Falcon specific fixes and improvements by Mikro. This should be the most complete and bug-free Atari Falcon release in years, so enjoy! :)

Atari800 version 3.0.0 (released on 2013/03/03) --- New features: ------------- * Option to automatically save configuration on exit * More settings saved in configuration: - currently attached tape file - cartridge settings, including currently attached cartridges - state of R-Time 8 - system settings, including Mosaic/Axlon RAM size * New Tape Management menu - can now create blank tape images, switch tape to read/write in order to save additional data at the end of the current tape image, rewind/fast forward the tape, and mark it as read-only. See DOC/USAGE for details. * Displaying tape position when "Show sector/block counter" is enabled. * Reworked Cartridge Management menu - now displays filename of the attached cartridge. * Option to disable restarting of the machine after cartridge change. * When attaching a cartridge from the command line, cartridge type can now be specified using the new -cart-type and -cart2-type options. * New cartridge types supported: - OSS 8 KB cartridge - OSS two chip 16 KB cartridge (043M) - Blizzard 4 KB cartridge - AST 32 KB cartridge - Atrax SDX 64 KB cartridge - Atrax SDX 128 KB cartridge - Turbosoft 64 KB cartridge - Turbosoft 128 KB cartridge - Ultracart 32 KB cartridge - Low bank 8 KB cartridge - SIC! 128 KB cartridge - SIC! 256 KB cartridge - SIC! 512 KB cartridge - Standard 2 KB cartridge - Standard 4 KB cartridge - Right slot 4 KB cartridge * The configure script can now auto-detect some of the available display and sound interfaces before compiling. * Option to enable XEP80 added to The Emulator Settings menu. * Emulation of the 1200XL, including console LEDs, no built-in BASIC, the F1-F4 keys (mapped to arrow keys in the SDL version) and the on-board J1 jumper. * Emulation of the XE Game System, including the built-in game and detachable keyboard. * Revamped the Select System menu (now called System Settings). Can now select many system settings, including RAM expansions, OS and BASIC revision, and more. * System ROM settings moved to a separate menu. Now it stores paths to all known official revisions of the Atari OS, the 5200 BIOS, all BASIC revisions, and the XEGS built-in game. The OS revision to use is chosen automatically when selecting a machine type (for example, the 400/800 OS PAL or NTSC version is chosen depending on the selected TV system). * 400/800: Emulation of all RAM sizes achievable with different combinations of the CX852 and CX853 modules - from 8 to 48 KB. * Emulation of 32/48KB memory sizes in the XL/XE mode, compatible with memory expansions for the 600XL manufactured by RC Systems. * Emulation of the MapRAM hardware hack. * Display settings: "Hue" renamed to "Tint". Tint now configurable also in PAL mode. New Android port features: -------------------------- * Renamed Atari800 Android port to "Colleen" * Implemented extended key remapping * Implemented the B: device (8-bit games can reach the web now) * Support for Xperia play keycodes added * Remapped dpad enter to break * Added paddle emulation * Optimized file selector, allow roaming outside of ext. storage dir * Added an exclusion border for paddle mode * Implemented state saving * Implemented Planetary Defense mode, a Koala Pad click-where-I-point mode * Natively supported UI on post-Honeycomb devices * Fixes for Jelly Bean (audio stuttering, keypad dialogs, soft keyboard) * Added new dialog for cartridge type selection * UI fine tuning General Fixes: -------------- * Bugfixes in cassette emulation - works reliably even for tape images with long (> 4096 B) blocks. * Fixes in save states - loading of save states works correctly even with an attached bank-switched cartridge or with an Axlon/Mosaic RAM expansion. Note 1: Format of the state files has changed. Old save states can still be opened, but newly-created ones cannot be opened in older versions of Atari800. Note 2: Tape position is not restored on loading of save states. Do not save state during tape loading/saving - it won't work as expected. * "Disable BASIC when booting Atari" no longer emulates pressing of the Option key when in the 400/800 mode. * Fixed a bug with BASIC sometimes disabling itself when switching system type to 400/800 * Minor bugfixes in file selector * Fixed emulation of SpartaDOS X piggyback cartridge functionality * "Save Screenshot" fixed - it saved an interlaced screenshot instead of a normal one. * SDL version: Swapped mapping of right and middle mouse buttons, to make it identical to the X11 and Win32 ports. * Monitor: fixed displaying/disassembling of memory area $D000-$D7FF - with the new supported cartridge types, code may reside on page $D5, and now it can be debugged. * SDL version: fixed a blue border when in OpenGL BGRA32 mode. * Minor fixes in parsing of command-line options. * Rewritten XEP80 emulation - now more accurate and supports switching between NTSC/PAL modes with correct aspect ratio. XEP80 emulation now requires a charset ROM image, path to which should be set in the XEP80_CHARSET line in the config file. * Fixed operating system patches not working with all official revisions of the OS. * Fixed emulation of separate ANTIC/CPU access to XE RAM when Self-Test is enabled. * Fixed the emulator menu sometimes being displayed incorrectly (missing font) when running without an OS ROM image. * Improved accuracy of generated colours in PAL mode. * Fixed emulation of the H: read operation - Turbo Basic's BLOAD now works on H: devices.

Atari800 emulator version 4.0.0 ------------------------------- This is a free and portable Atari 8-bit computer and 5200 console emulator, originally written by David Firth and now developed by the Atari800 Development Team (please see DOC/CREDITS). This program is copyrighted and released under the GPL (see COPYING). Please read DOC/README, DOC/INSTALL and DOC/USAGE. For news in this release please do read DOC/NEWS. If you have a problem running this emulator please read DOC/FAQ first. If the problem persists then please ask in newsgroup comp.sys.atari.8bit or in the atari800-users mailing list (see below). Look at DOC/BUGS before reporting something you consider a bug. If you want to help developing Atari800 emulator you can subscribe to our mailing list (http://lists.sourceforge.net/lists/listinfo/atari800-users). DOC/TODO might point you in the right direction. This version, and all versions back to 0.8.2 have been released by me (Petr Stehlik) and are now available at Sourceforge.net (URL below). Thanks go to David Firth and all the people that helped making this release. EnJoy! Petr Stehlik April 21, 2018 E-mail: pstehlik@sophics.cz Project homepage: http://atari800.github.io/

Version 4.1.0 (2019/04/13) ==================== New Features: ------------- * Atari800 now includes Altirra BIOS-es for all emulated systems: 400/800, XL/XE, and 5200; as well as Altirra BASIC. It is now possible to use the emulator without providing any ROM images. * The Altirra OS-es and Altirra BASIC can now be selected by users in the "System settings", if they want to use them. Previously Altirra OS was used automatically only when no other OS ROMs were found. * joyhat support for all four real joysticks, configurable in CLI/cfg/TUI Notable changes: ---------------- * All documentation specific to building Atari800 on Windows has been moved from DOC/INSTALL to a new file, DOC/BUILD.windows. This document has also been expanded with a new chapter covering building Atari800 using MSYS2. * Ability to use the built-in EmuOS firmware has been removed. Users wishing to run Atari800 without providing OS ROMs now have an option of using the built-in Altirra OS-es, which are compatible with much more Atari software than EmuOS. At the same time, it is still possible to compile a version of Atari800 without any OS ROMs built in, by means of the --disable-altirra_bios configure option. Port specific improvements: --------------------------- == Atari Falcon == * More Videl/screen handling fixes * Ability to run Atari800 in an AES-less environment * Replaced C2P with MMU friendly and faster code * Atari800 should run on all TOS clones with XBIOS Sound API == Android == * Fixed building of the Android target, broken in the previous release. * Fixed labels on console keys (unreadable on hi-res displays) * Fixed console keys press detection * Fixed "right-handed joystick" trigger press == Raspberry Pi == * updated build documentation * find proper Broadcom GLes libraries * fixed bug in GRAPHICS 9 (shifted colors) == MS Windows == * updated build documentation General Fixes: -------------- * updated build documentation * it is possible to build atari800 out of source tree * unconnected host joysticks initialized properly, fixes the MULE game
